Pro-face PFXGP6500TAA 10.4-Inch AC HMI Touch Panel
The PFXGP6500TAA is a 10.4-inch GP6000 Series HMI featuring an 800 × 600 SVGA TFT display, analog resistive touch input, dual Ethernet and serial interfaces, and a 100–240 VAC power supply for industrial machine operation and monitoring.
1-Year Product Warranty
KWOCO supplies only new original products. All products we sell are covered by a 1-year warranty. View warranty terms →
Tell us the model and quantity. We will quote the total cost to your destination.
Stock Available
Fast stock check and quick shipment for common industrial automation parts.
Global Shipping
Reliable delivery to the USA, Europe and other major industrial markets.
New Original Only
We supply new original products and confirm product condition before shipment.
Flexible Payment
T/T, PayPal and flexible terms can be discussed for qualified customers.
One-Stop Sourcing
PLC, HMI, servo, inverter, sensor, cable and spare parts sourcing support.
Pro-face PFXGP6500TAA Basic Specifications
| Product Type | Human Machine Interface (HMI) |
|---|---|
| Model | PFXGP6500TAA |
| Series | Pro-face GP6000 Series, Standard Model |
| Display | 10.4-inch TFT color LCD; SVGA 800 × 600 pixels; 16 million colors; 211.2 × 158.4 mm effective display area |
| Touch Panel | Analog resistive film, single touch; 1,024 × 1,024 resolution; 1 million operations minimum |
| Backlight | White LED; 50,000 hours minimum service life at 25°C; brightness adjustment from 0 to 100 |
| Memory | 4 GB eMMC system memory; 64 MB screen area; 512 KB NVRAM backup memory |
| Communication Interfaces | 2 × 10BASE-T/100BASE-TX Ethernet; COM1 RS-232C; COM2 RS-422/485; 1 × USB 2.0 Type-A; 1 × USB 2.0 Micro-B |
| External Storage | 1 × SD card slot supporting SD, SDHC and SDXC cards with UHS-I support |
| Power Supply | 100 to 240 VAC, 50/60 Hz; allowable input range: 85 to 264 VAC; maximum consumption: 18.3 VA at 100 VAC or 29.1 VA at 240 VAC |
| Protection and Environment | IP65F front face when correctly panel-mounted; 0 to 55°C; 10% to 90% RH, non-condensing |
| Dimensions and Installation | 272.5 × 214.5 × 58.5 mm; panel cutout: 259 × 201 mm; panel thickness: 1.6 to 5 mm; weight: 1.9 kg maximum |
| Programming Software | GP-Pro EX Version 5.00 or later |
| Application | Machine visualization, operator control, process monitoring, production equipment and GP4000-series modernization |
| Condition | New original product |
| Warranty | 12-month warranty from KWOCO |
About Pro-face PFXGP6500TAA Touch Panel
The PFXGP6500TAA is a Pro-face GP6000-series HMI designed for machine visualization, operator control and production-status monitoring. Its 10.4-inch SVGA display, AC power input and multiple industrial communication interfaces make it suitable for new control panels and supported GP4000-series modernization projects.
Key Features
- 10.4-inch SVGA display: Presents machine graphics and operating information at 800 × 600 resolution with 16 million colors.
- Analog resistive touch panel: Provides precise single-touch operation with a touch resolution of 1,024 × 1,024.
- Wide-range AC power input: Operates directly from a 100 to 240 VAC industrial power supply.
- Dual Ethernet connectivity: Includes two 10BASE-T/100BASE-TX ports for controller communication and network integration.
- Two industrial serial ports: Provides RS-232C and RS-422/485 interfaces for connecting PLCs, drives and other serial devices.
- USB and SD storage support: Includes USB Type-A, USB Micro-B and an SD card slot for data handling, maintenance and project transfer.
- Supported GP4000 migration path: Identified by Pro-face as the recommended GP6000 substitute for the AC-powered PFXGP4501TAA, subject to migration checks.
Installation Note
The TAA suffix identifies the analog-touch, AC-powered version. Do not replace it with a TAD, TMA or TMD model without checking the power supply and touch-panel requirements. The AC model requires protective grounding, and its serial interfaces are not isolated. IP65F protection applies to the front face only when the panel and gasket are installed correctly.
Matching Modules & One-Stop Sourcing
Complete your automation system with compatible Proface components. KWOCO helps customers source PLC modules, power supply units, communication modules, cables and other industrial spare parts together.
Need a custom BOM or module not listed on this page?
Send us your part list and quantity. We will help check stock, price, lead time and shipping options for your order.
Trusted by Global Industrial Buyers
KWOCO supports overseas customers with new original automation parts, fast delivery, and reliable after-sales service for maintenance and project procurement.
USA Engineering Project Customer
Supplied Omron PLC modules and related automation parts for a project customer in the USA, supporting maintenance replacement and fast project delivery.
Japanese Listed Company Cooperation
Long-term cooperation with a Japanese listed company, supplying PLC spare parts and automation components for maintenance and replacement needs.
European Factory Customer
Provided Omron PLC modules and industrial automation parts for a European factory customer, helping reduce downtime and support production line maintenance.
After-Sales Service & Warranty
Warranty Support
All products are covered by a 12-month warranty from the date of delivery.
Return Support
Return or exchange support is available within 30 days for eligible products.
Technical Support
We help confirm product details and suggest suitable replacement models.
Fast Response
Our team responds quickly to quality, delivery, and after-sales questions.
Overseas Support
We support overseas buyers with automation spare-parts sourcing experience.
Frequently Asked Questions
Which software is used to program the PFXGP6500TAA?
The PFXGP6500TAA is configured with Pro-face GP-Pro EX. GP6000 Series support was introduced with GP-Pro EX Version 5.00, so Version 5.00 or later should be used to create and transfer projects.
Can the PFXGP6500TAA replace the PFXGP4501TAA?
Pro-face lists the PFXGP6500TAA as the recommended GP6000 replacement for the PFXGP4501TAA. The panel cutout remains 259 × 201 mm, but the new unit is slightly deeper and uses USB Micro-B instead of Mini-B. Project conversion, communication cables and installation accessories must be checked before replacement.
Does the PFXGP6500TAA require AC or DC power?
It is an AC-powered model rated for 100 to 240 VAC, with an allowable range of 85 to 264 VAC. For a 24 VDC version with analog touch, the related model is PFXGP6500TAD.
Does the PFXGP6500TAA support multi-touch operation?
No. It uses an analog resistive single-touch panel. Touching multiple points can be interpreted as a touch near their center, so safety-related screens should be designed for single-point operation.
What communication ports are available on the PFXGP6500TAA?
It provides two 10/100 Mbps Ethernet ports, one RS-232C port, one RS-422/485 port, USB Type-A, USB Micro-B and an SD card slot. PLC compatibility still depends on the selected GP-Pro EX communication driver, cable and device settings.
