Pro-face PFXET6400WAD 7-Inch ET6000 HMI Touch Panel
The PFXET6400WAD is a 7-inch wide HMI from the Pro-face ET6000 Series, featuring an 800 × 480 TFT color display, analog resistive touch panel, Ethernet, dual serial ports and 24 VDC operation for compact machine visualization and control.
1-Year Product Warranty
KWOCO supplies only new original products. All products we sell are covered by a 1-year warranty. View warranty terms →
Tell us the model and quantity. We will quote the total cost to your destination.
Stock Available
Fast stock check and quick shipment for common industrial automation parts.
Global Shipping
Reliable delivery to the USA, Europe and other major industrial markets.
New Original Only
We supply new original products and confirm product condition before shipment.
Flexible Payment
T/T, PayPal and flexible terms can be discussed for qualified customers.
One-Stop Sourcing
PLC, HMI, servo, inverter, sensor, cable and spare parts sourcing support.
Proface PFXET6400WAD Basic Specifications
| Product Type | Human Machine Interface (HMI) |
|---|---|
| Model | PFXET6400WAD |
| Series and Model Name | Pro-face ET6000 Series, ET-6400WA |
| Display | 7-inch wide TFT color LCD; WVGA 800 × 480 pixels; 16 million colors; 154.08 × 85.92 mm effective display area |
| Backlight | White LED; 50,000 hours minimum service life at 25°C; 16-level brightness control |
| Touch Panel | Analog resistive film, single touch; 1,024 × 1,024 touch resolution; 1 million operations minimum |
| Memory | 32 MB screen area; 128 KB backup memory |
| Communication Interfaces | Ethernet: 1 × 10BASE-T/100BASE-TX RJ45; COM1: RS-232C; COM2: RS-422/485; 1 × USB 2.0 Type-A; 1 × USB 2.0 Micro-B |
| Power Supply | 24 VDC rated input; 19.2 to 28.8 VDC allowable range; 9 W power consumption |
| Protection and Environment | IP65 front face when correctly panel-mounted; 0 to 50°C; 10% to 90% RH, non-condensing |
| Dimensions and Weight | 205.5 × 150.5 × 45 mm (W × H × D); 0.61 kg maximum |
| Panel Cutout | 190 × 135 mm; applicable panel thickness: 1.6 to 5 mm |
| Application | Machine visualization, operator control, equipment monitoring, production-line operation and HMI replacement |
| Condition | New original product |
| Warranty | 12-month warranty from KWOCO |
About Pro-face PFXET6400WAD 7-Inch HMI Touch Panel
The PFXET6400WAD is a Pro-face ET6000-series HMI designed to provide machine visualization, operator input and equipment-status monitoring in a compact panel-mounted format. It is suitable for industrial machines and production equipment requiring Ethernet connectivity, serial-device communication and straightforward touch operation.
Key Features
- 7-inch WVGA display: Provides an 800 × 480 widescreen interface with 16 million colors for clear machine graphics and operating information.
- Analog resistive touch control: Supports reliable single-touch operation and can be used with a finger or an appropriate touch-panel stylus.
- Dual serial communication: Includes an RS-232C port and an RS-422/485 port for connecting PLCs, controllers and other serial devices.
- Built-in Ethernet interface: Supports 10BASE-T and 100BASE-TX communication through one RJ45 port.
- USB connectivity: Provides USB Type-A for peripheral or storage connections and Micro-B for project transfer and maintenance.
- 24 VDC industrial power input: Operates from 19.2 to 28.8 VDC with a rated power consumption of 9 W.
- Compact panel installation: Uses a 190 × 135 mm panel cutout and has a mounting depth of 45 mm for space-conscious control cabinets.
Installation Note
The specified IP65 protection applies to the front face only when the HMI is correctly installed in a solid panel with the installation gasket. The COM1 and COM2 serial interfaces are not isolated, so grounding and potential ground-loop conditions must be checked before connecting external equipment.
