Omron XS2F-M12PVC4S5M 5 m M12 Sensor Connection Cable
The XS2F-M12PVC4S5M is a 5 m sensor connection cable with a straight A-coded M12 female socket, four conductors and an open cable end, providing an IP67-rated connection for sensors and industrial automation equipment.
1-Year Product Warranty
KWOCO supplies only new original products. All products we sell are covered by a 1-year warranty. View warranty terms →
Tell us the model and quantity. We will quote the total cost to your destination.
Stock Available
Fast stock check and quick shipment for common industrial automation parts.
Global Shipping
Reliable delivery to the USA, Europe and other major industrial markets.
New Original Only
We supply new original products and confirm product condition before shipment.
Flexible Payment
T/T, PayPal and flexible terms can be discussed for qualified customers.
One-Stop Sourcing
PLC, HMI, servo, inverter, sensor, cable and spare parts sourcing support.
Omron XS2F-M12PVC4S5M Basic Specifications
| Product Type | Sensor I/O Connector Cable |
|---|---|
| Model | XS2F-M12PVC4S5M |
| Series | Omron XS2F-M12 Series |
| Connector Configuration | Straight M12 female socket to open cable end |
| Coding and Fastening | A-coded, M12 × 1 threaded connection |
| Number of Contacts | 4 poles, 4 conductors |
| Cable Specifications | Black flame-retardant PVC cable, 5 m length, 5 mm outer diameter, AWG23 (0.25 mm²) |
| Wiring | Pin 1: Brown; Pin 2: White; Pin 3: Blue; Pin 4: Black |
| Rated Voltage and Current | 125 VDC, 4 A |
| Electrical Performance | 40 mΩ maximum contact resistance; 1,000 MΩ minimum insulation resistance; 1,500 VAC dielectric strength for 1 minute |
| Protection and Temperature | IP67 according to IEC 60529; -10 to 80°C |
| Application | Sensor and actuator wiring, industrial automation equipment, machine control and maintenance replacement |
| Condition | New original product |
| Warranty | 12-month warranty from KWOCO |
About Omron XS2F-M12PVC4S5M Sensor Connection Cable
The XS2F-M12PVC4S5M is an Omron XS2F-series sensor connection cable designed to connect compatible M12 sensors and actuators to control-system wiring. It is commonly used in industrial automation and machine-control applications where a preassembled connector, color-coded conductors and reliable environmental protection are required.
Key Features
- Straight M12 female connection: Provides a standard A-coded M12 socket with a threaded locking mechanism for compatible industrial sensors and actuators.
- Four-conductor wiring: Uses four color-coded leads for straightforward identification during control-panel and field wiring.
- Five-metre cable length: Provides additional installation reach between field devices and junction boxes or control equipment.
- Industrial electrical rating: Supports a rated voltage of 125 VDC and a rated current of 4 A.
- IP67 environmental protection: Helps protect the properly connected interface against dust and temporary water exposure.
- Flame-retardant PVC cable: Uses a black 5 mm-diameter PVC cable with AWG23 conductors for standard factory applications.
- Preassembled open-end design: Reduces connector assembly work while allowing the free cable end to be terminated according to the application.
Installation Note: Confirm the mating connector, voltage rating and pin assignment before installation. Omron specifies tightening the M12 locking ring by hand to a torque of 0.39 to 0.49 N·m.
