Omron R88M-1M60020C-BS2 1S Series AC Servo Motor, 600W, 400VAC
Omron 1S Series AC Servo Motor, 600W (0.6kW) rated output, 400 VAC three-phase supply voltage, 2000 r/min rated speed, 2.86 Nm rated torque, 8.59 Nm peak torque, equipped with a 23-bit battery-free absolute multi-turn encoder, built-in brake.
* Send us your inquiry and get direct help from our team.
Technical Specifications Table
Belonging to the advanced Omron 1S Series, the R88M-1M60020C-BS2 is a high-performance AC servo motor engineered to deliver precise motion control and maximize machine productivity. With a 600W power rating and a robust 400 VAC supply compatibility, it provides stable, continuous operation in demanding industrial applications.
The integration of a 23-bit high-resolution, battery-free absolute encoder ensures highly accurate positioning without the maintenance overhead of battery replacements, simplifying the overall machine design and reducing long-term upkeep.
| Item | Description |
|---|---|
| Brand | Omron |
| Series | 1S Series |
| Part Number | R88M-1M60020C-BS2 |
| Rated Output | 600 W (0.6 kW) |
| Drive Supply Voltage | 400 VAC (Three phase) |
| Rated Speed | 2000 r/min |
| Rated Torque | 2.86 Nm |
| Peak Torque | 8.59 Nm |
| Encoder Type | Battery-free Absolute multi-turn encoder |
| Encoder Resolution | 23-Bit |
| Motor with Brake | Yes (Built-in) |
| Shaft Configuration | Shaft with Key and Tap |
| Shaft Diameter | 19 mm |
| Flange Size Square (LC) | 100 mm |
| Product Weight | 5800 g (5.8 kg) |
Key Features
- Battery-Free Absolute Encoder: High-resolution 23-bit multi-turn encoder eliminates the need for battery maintenance and routine backup procedures.
- Integrated Holding Brake: Safely secures vertical or heavy loads during power interruptions or emergency stops, significantly enhancing overall machine safety.
- Optimized Form Factor: The compact 100mm square flange size minimizes the installation footprint while still delivering a robust 2.86 Nm rated torque.
- High-Speed Operation: Achieves a rated rotational speed of 2000 r/min, supporting rapid machine cycles, precise positioning, and higher throughput.
- Secure Mechanical Coupling: The 19mm shaft includes a key and tap, ensuring slip-free mechanical connection to gearboxes, pulleys, and load actuators.
- Simplified System Wiring: Compatible with pre-assembled Omron motor cables, reducing field installation time and minimizing wiring errors.
Applications
The precise control, rapid processing speed, and integrated safety brake of the Omron R88M-1M60020C-BS2 make it a highly versatile servo motor for a wide spectrum of automated manufacturing environments. It is specifically suited for vertical motion applications and complex synchronized tasks where exact positioning and holding force are non-negotiable.
- Packaging Machinery: Drives feeding, sealing, and cutting mechanisms with precise speed synchronization to maximize throughput and minimize material waste.
- Material Handling & Conveyors: Controls multi-axis gantries and vertical hoists reliably, utilizing the built-in brake for secure load holding during transit.
- Robotics & Articulated Arms: Powers robotic joints efficiently with its high peak torque (8.59 Nm) and compact footprint, enabling rapid, precise end-of-arm movements.
- Semiconductor Manufacturing: Ensures vibration-free, highly exact positioning of wafers and delicate components by utilizing the 23-bit absolute encoder.
- Textile Processing: Maintains consistent tension control and rotational synchronization across multiple drive points for continuous, smooth fabric production.
- CNC and Machining Centers: Delivers stable, continuous torque for accurate tool positioning and automated workpiece feeding in metal and woodworking machinery.
Why Choose Kwoco
- 100% Brand New & Original: We strictly guarantee that every Omron R88M-1M60020C-BS2 supplied is authentic and factory-new, eliminating the operational risks associated with refurbished or used parts.
- Ready Stock Availability: Through extensive inventory management, we maintain ready stock of critical automation components to help minimize your facility’s downtime.
- Fast Global Shipping: We utilize premium international logistics networks to ensure rapid, secure delivery to the USA, Germany, Italy, France, the Netherlands, Spain, and beyond.
- One-Stop Sourcing Hub: Streamline your entire procurement cycle by sourcing PLCs, HMIs, Servo drives, and sensors from multiple leading industrial brands through a single, reliable partner.
- Rapid B2B Response: Our dedicated sales and technical support teams provide fast, accurate quotations and commercial support to meet your urgent project deadlines.
- Rigorous Quality Control: Every product undergoes stringent pre-shipment inspection to verify that packaging and component integrity meet the highest B2B purchasing standards.
Frequently Asked Questions
The “B” specifies that the motor is equipped with a built-in holding brake, while “S2” indicates that the motor shaft includes a key and tap for secure mechanical connections.
Yes, the R88M-1M60020C-BS2 features a 23-bit absolute multi-turn encoder that does not require a battery backup. This design eliminates routine battery replacement tasks and reduces maintenance costs.
This specific model operates on a 400 VAC three-phase supply voltage, delivering a rated output of 600W (0.6kW).
No, Kwoco exclusively supplies 100% brand new and original industrial automation products. We do not deal in used, refurbished, or aftermarket items.
