Omron CP Series CP1H CPU Unit CP1H-X40DT1-D In Stock
PLC, 24 VDC supply, 24 x 24 VDC inputs, 16 x PNP outputs 0.3 A, 1 x analog input, 20K steps program + 32K words data memory.
Key Features and Technical Specifications
The CP1H-X40DT1-D comes equipped with robust features designed for industrial applications:
- Input/Output Configuration:
- 24 digital inputs (24VDC)
- 16 transistor outputs (PNP type)
- Expandable I/O capabilities
- Memory and Processing:
- 32K steps program memory
- High-speed processing unit
- Built-in data memory for efficient operations
- Communication Capabilities:
- USB port for programming
- RS-232C serial port
- Optional Ethernet connectivity
| Parameter | Value |
|---|---|
| Supply voltage type | DC |
| Number of digital inputs | 24 |
| Input type | PNP/NPN |
| Number of digital outputs | 16 |
| Output type | PNP |
| Program capacity | 20 K steps |
| Data memory capacity | 32 K words |
| Logic execution time | 0.10 µs |
| Communication port(s) | USB |
| Number of USB ports | 1 |
| Communication option(s) | CAN, CompoBus/S Master, CompoBus/S Slave, CompoNet Master, DeviceNet Master, DeviceNet Slave, EtherCAT Slave, EtherNet/IP, Ethernet TCP/IP, MODBUS Master, MODBUS Slave, PROFIBUS DP Master, PROFIBUS DP Slave, PROFINET Master, Serial RS-232C, Serial RS-422, Serial RS-485 |
| Number of encoder input channels | 4 |
| Max. encoder input frequency | 100 kHz |
| Max. number of PTP axes | 4 |
| Max. pulse output frequency | 100 kHz |
| Max. number of analogue I/O channels | 56 |
| Max. number of local I/O points | 320 |
| Max. number of expansion units | 7 |
| Operating temperature range | 0-55 °C |
| Product Height (unpacked) | 90 mm |
| Product Width (unpacked) | 150 mm |
| Product Depth (unpacked) | 85 mm |
| Product Weight (unpacked) | 600 g |
How Does CP1H-X40DT1-D Compare to Other PLCs?
When comparing the CP1H-X40DT1-D to other PLCs in its class, several advantages stand out:
- Superior Position Control
- Built-in pulse outputs for axis control
- Advanced motion capabilities
- Integrated positioning functions
- Expandability Options
- Supports CP1W expansion units
- DeviceNet master/slave capability
- CompoNet master functionality
Installation and Setup Guide
DIN Rail Mounting
- Secure the DIN rail mounting bracket
- Snap the unit onto the DIN rail
- Connect the 24VDC power supply
Wiring Considerations:
- Use proper cable shielding
- Follow recommended grounding practices
- Implement noise prevention measures
CP1H-X40DT1-D Product Datasheet
Frequently Asked Questions
The CP1H-X40DT1-D supports up to 7 expansion units, allowing for significant I/O expansion capabilities.
Firmware updates can be performed through the USB port using CX-One software.
The PLC supports DeviceNet, CompoNet, and Ethernet networks through optional communication units.
Yes, remote programming is supported through both serial and Ethernet connections when properly configured.
