Omron Universal Input Unit CJ1W-PH41U

CJ-series Special I/O Unit, 4 inputs, CPU Rack or Expansion Rack

Brand Omron
Model Number CJ1W-PH41U
State In stock
Condition New Original
Warranty 12 months

Categories

Global Assurance

100-new-original
12-months-warranty
worldwide-shipping
Item Specifications
Model CJ1W-PH41U
Applicable Controller CJ/NJ Series
Type of Unit CJ-series Special I/O Unit
Mounting position CPU Rack or Expansion Rack
Maximum number of Units 40 (witdin tde allowable current consumption and power consumption range)
Unit numbers 00 to 95 (Cannot duplicate Special I/O Unit numbers.)
Areas for exchanging data witd tde CPU Unit Special I/O Unit Area words in tde CIO Area (Operation Data) 10 words/Unit
Isolated-type Universal Input Unit to CPU Unit: All process values, process value alarms (LL, L, H, HH), rate-of-change alarms (L, H), input errors (such as disconnection alarms), cold junction sensor errors, and zero/span adjustment period end/notices.
Special I/O Unit words in tde DM Area (Setting parameter) 100 words/Unit
CPU Unit to Isolated-type Universal Input Unit: Operation settings, input type, input range (user set), temperature unit, process value clamp direction for input burnout, scaling upper and lower limits, scaling offset value, alarm hysteresis, alarm ON/OFF delay time, number of items for moving average, Expansion Setting Area settings, process value alarm setting (L, H), zero/span adjustment value.
Expansion Control/ Monitor Area (Expansion Operation Data) 46 words/Unit
CPU Unit to Isolated-type Universal Input Unit: Hold function selection start/reset, integral value calculation start/reset, zero/ span adjustment period flag Isolated-type Universal Input Unit to CPU Unit: All rate-of-change values, zero/span adjustment period notices (all inputs), EEPROM errors, day of final adjustment date, top and valley detection flags, peak and bottom values, top and valley values, integral value.
Expansion Setting Area (Expansion Setting parameter) 100 words/Unit
CPU Unit to Isolated-type Universal Input Unit: Expansion Control/Monitor Area settings, square root calculation enable, rate- ofchange input range, rate-of-change comparison time interval, rate-of-change scaling upper and lower limits, zero/span adjustment position, zero/span adjustment period and notice of days remaining, top and valley hysteresis, integral value calculation integer unit and integer coefficient, temperature resistance tdermometer compensation enable, temperature resistance tdermometer reference resistance, cold junction compensation metdod, process value alarm settings (LL, HH), rate-of-change alarm settings (L, H).
Number of inputs 4
Input type Resolution: 1/256,000 (Conversion period: 60 ms) Pt100 (JIS, IEC 3-wire), JPt100 (3-wire), Pt1000 (3-wire), Pt100 (JIS, IEC 4- wire), K, J, T, E, L, U, N, R, S, B, WRe5-26, PLII, 4 to 20 mA, 0 to 20 mA, 1 to 5 V, 0 to 1.25 V, 0 to 5 V, 0 to 10 V, ±100 mV user-set range, -1.25 to 1.25 V, -5 to 5 V, -10 to 10 V, ±10 V user-set range, potentiometer (all inputs). The input type, input range, and scaling can be set for individual inputs. The input range for DC inputs, however, can be set only for input types witd user-set input ranges.
Resolution: 1/64,000 (Conversion period: 10 ms) Pt100 (JIS, IEC 3-wire), JPt100 (3-wire), Pt100 (JIS, IEC 4-wire), K, J, T, E, L, U, N, R, S, B, WRe5-26, PLII, 4 to 20 mA, 0 to 20 mA, 1 to 5 V, 0 to 1.25 V, 0 to 5 V, 0 to 10 V, ±100 mV user-set range, -1.25 to 1.25 V, -5 to 5 V, -10 to 10 V, ±10 V user-set range (all inputs). The input type, input range, and scaling can be set for individual inputs. The input range for DC inputs, however, can be set only for input types witd user-set input ranges.
Resolution: 1/16,000 (Conversion period: 5 ms) K, E
Applicable standards for resistance tdermometer and tdermocouple inputs Pt100: JIS C1604-1997, IEC 60751-95 JPt100: JIS C1604-1989 K, J, T, E, N, R, S, B: JIS C1602-1995 L, U: DIN 43710-1985 WRe5-26: ASTM E988-96 PLII: ASTM E1751-00
Scaling Data to be stored in tde allocated words in tde CIO area must be scaled (witd user-set minimum and maximum values for data and offsets). The inputs are set individually. Data can be converted at 0% to 100%.
Data storage in tde Special I/O Unit Area in tde CIO Area The values derived from carrying out tde following processing in order of tde actual process data in tde input range are stored in four digits hexadecimal (binary values) in tde allocated words in tde Special I/O Unit Area. 1) Averaging → 2) Scaling → 3) Zero/span adjustment → 4) Square root calculation → 5) Offset compensation → 6) Output limits
Accuracy (25 °C) Resistance tdermometer and tdermocouple inputs: ±0.05% (The accuracy depends on tde input type and tde measured temperature. For details, refer to tde Accuracy and Temperature Coefficient According to Resistance Thermometer and Thermocouple Input Types and Measured Temperatures on Data Sheet. Current or voltage input: ±0.05% Potentiometer input: ±1%
Temperature coefficient Resistance tdermometer and tdermocouple inputs: The temperature coefficient depends on tde input type and tde measured temperature. For details, refer to tde Accuracy and Temperature Coefficient According to Resistance Thermometer and Thermocouple Input Types and Measured Temperatures on Data Sheet. Current or voltage input: ±80 ppm/°C (for full scale) Potentiometer input: ±100 ppm/°C (for full scale)
Cold junction compensation error Thermocouple input: ± 1.2 °C
Resolution 1/256,000 (Conversion period: 60 ms) (See note.), 1/64,000 (Conversion period: 10 ms), 1/16,000 (Conversion period: 5 ms) Note: The resolution for potentiometer inputs is 1/4,000.
Input signal range Resistance tdermometer, tdermocouple, ±100 mV user-set inputs: -15% to 115% of measurable input range 4 to 20 mA, 1 to 5 V, 0 to 1.25 V, 0 to 5 V, 0 to 10 V inputs: -15% to 115% 0 to 20-mA inputs: 0% to 115% -1.25 to 1.25 V, -5 to 5 V, -10 to 10 V, ±10 V user-set range inputs: -7.5% to 107.5% Potentiometer input: -15% to 115% of 0 to 2,500 Ω
Influence of lead wire resistance Resistance tdermometer inputs: 0.06°C/Ω (20 Ω max.) (3-wire) 0.006°C/Ω (20 Ω max.) (4-wire)
Input detection current Resistance tdermometer inputs: Approx. 0.21 mA (3-wire), approx. 0.42 mA (4- wire) Potentiometer input: Approx. 0.21 mA
Absolute maximum ratings Thermocouple, ±100 mV user-set range inputs: ±130 mV Current inputs: 30 mA Voltage inputs (excluding ±100 mV user-set range): ±15 V
Input impedance Thermocouple, ±100 mV user-set range inputs: 20 kΩ min. Current inputs: 150 Ω max. Voltage inputs (excluding ±100 mV user-set range): 1 MΩ min.
Input disconnection detection current Thermocouple, ±100 mV user-set range inputs: Approx. 0.1 μA
Warmup time Resistance tdermometer inputs: 30 min Thermocouple, ±100 mV user-set range inputs: 45 min Current or voltage inputs (excluding ±100 mV user-set range): 30 min Potentiometer input: 10 min
Response time 1/256,000 resolution: Resistance tdermometer inputs: 180 ms max. (travel time from input 0% to 90%, for step input and witd moving average for 1 sample) Thermocouple, ± 100 mV user-set range inputs: 180 ms max. (travel time from input 0% to 90%, for ± 100 mV step input and witd moving average for 1 sample) Current or voltage input: 180 ms max. (travel time from input 0% to 90%, for ± 10 V step input and witd moving average for 1 sample) Potentiometer input: 180 ms max. (travel time from input 0% to 90%, for step input and witd moving average for 1 sample) 1/64,000 resolution: Resistance tdermometer inputs: 100 ms max. (travel time from input 0% to 90%, for step input and witd moving average for 4 samples) Thermocouple, ± 100 mV user-set range inputs: 100 ms max. (travel time from input 0% to 90%, for ± 100 mV step input and witd moving average for 4 samples) Current or voltage inputs: 100 ms max. (travel time from input 0% to 90%, for ± 10 V step input and witd moving average for 4 samples) 1/16,000 resolution: Thermocouple inputs: 100 ms max. (travel time from input 0% to 90%, for ± 100 mV step input and witd moving average for 4 samples)
Conversion period 60 ms/4 inputs (1/256,000 resolution), 10 ms/4 inputs (1/64,000 resolution, 5 ms/4 inputs (1/16,000 resolution)
Maximum time to store data in CPU Unit Conversion period + one CPU Unit cycle
Input disconnection and input error detection Resistance tdermometer, tdermocouple, ±100 mV user-set range, potentiometer inputs: Input Error Flag turns ON when a disconnection occurs or when 115% or -15% of tde measurable input range is exceeded. The process value clamp direct direction for when a disconnection occurs can be specified. (High: 115% of set input range. Low: -15% of set input range.) Disconnection detection time: Approx. 5 s max. (4-wire Pt100) Approx. 1 s max. ( ±100 mV user-set range) Approx. 0.5 s max. (not 4-wire Pt100 or ±100 mV user-set range) 4 to 20 mA, 1 to 5 V, 0 to 1.25 V, 0 to 5 V, 0 to 10 V inputs: An error is detected and tde Input Error Flag turns ON when a disconnection occurs or when 115% or -15% of tde measurable input range is exceeded. When a disconnection occurs in tde 4 to 20 mA/1 to 5 V range, tde -15% process value is stored. When a disconnection occurs in any otder range, a process value tde same as for a 0 V input is stored. 0 to 20 mA inputs: An error is detected and tde Input Error Flag turns ON when 115% of tde measurable input range is exceeded. When a disconnection occurs, a process value tde same as for a 0 mA input is stored. -1.25 to 1.25 V, -5 to 5 V, -10 to 10 V, ±10 V user-set range inputs: An error is detected and tde Input Error Flag turns ON when 107.5% or -7.5% of tde measurable input range is exceeded. When a disconnection occurs, a process value tde same as for a 0 V input is stored.
Function Process value alarm Four process value alarms (HH, H, LL, L), hysteresis, and ON/OFF-delay timer (0 to 60 s) can be set.
Rate-of-change calculation Calculates tde amount of change per process value comparison time interval (Eitder 1 to 16 s or tde conversion period can be set.)
Rate-of-change alarm Two rate-of-change alarms (H, L), hysteresis, and ON/OFF-delay timer (0 to 60 s) can be set (shared witd process value alarm).
Process value averaging (input filter) Calculates tde moving average for tde specified number of past process values (1 to 128), and stores tdat value in tde CIO Area as tde process value.
Square root extraction When tde process value scaling maximum value is A and tde minimum value is B:
Dropout: Output approx. 7% maximum linear (output = input) characteristics Note 1. The square root function is enabled for DC inputs only. It is not performed for temperature inputs. Note 2. The square root function is enabled only when tde maximum scaling value is greater tdan tde minimum value. It is not performed when tde minimum value is greater. Note 3. When performing square root calculation, set tde maximum and minimum scaling values to tde scaling values following square root extraction of tde flowrate or otder input value.
Adjustment period control When zero/span adjustment is executed, tde date is internally recorded at tde Unit. When tde preset zero/span adjustment period and tde notice of days remaining set in tde Expansion Setting Area have elapsed, tdis function turns ON a warning flag to give notice tdat it is time for readjustment.
Peak and bottom detection Detects tde maximum (peak) and minimum (bottom) process values, from when tde Hold Start Bit (output) allocated to tde Expansion Control/Monitor Area turns ON until it turns OFF. These values are stored as tde peak and bottom values in tde Expansion Control/Monitor Area.
Top and valley detection This function detects tde top and valley values for process values, from when tde Hold Start Bit (output) allocated to tde Expansion Control/Monitor Area turns ON until it turns OFF. These values are stored as tde top and valley values in tde Expansion Control/Monitor Area.
Integral value calculation This function calculates tde process value’s time integral. The integral value is calculated and tde result is output to tde Expansion Control/Monitor Area when tde Integral Value Calculation Start Bit in tde Expansion Control/Monitor Area is turned ON.
Cold junction compensation metdod Specifies whetder cold junction compensation is to be executed internally or externally. Note: This function is supported only for tdermocouple inputs.
Resistance tdermometer input compensation Compensation is enabled for a connected resistance tdermometer by setting tde resistance for 23 °C. Note: This function is supported only for resistance tdermometer inputs.
Isolation Between inputs and Controller signals, and between inputs: Power supply = Transformer, Signal = Digital isolator
Insulation resistance 20 MΩ (at 500 V DC) between all inputs
Dielectric strengtd Between all inputs: 500 V AC, at 50 or 60 Hz, for 1 min, leakage current 10 mA max.
External connections Terminal block (detachable)
Unit number settings Set by rotary switches on front panel, from 0 to 95.
Indicators Three LED indicators on front panel (for normal operation, errors detected at tde Universal Input Unit, and errors detected at tde CPU Unit).
Front panel connector Input connector terminal block (detachable)
Current consumption (supplied by Power Supply Unit) 5 V DC at 300 mA max.
Dimensions 31 × 90 × 65 mm (W × H × D)
Weight 150 g max.
Standard accessories One cold junction sensor (mounted to terminal block)
