Schneider Electric BMXCPS3500 AC Power Supply Module
Power supply module X80, 100…240 V AC primary voltage, 36 W total useful secondary power, 0.52 A at 240 V input current, 4.5 A 3.3 V DC logic power, IP20 protection, internal fuse, overvoltage protection, 0.36 kg weight, status LED green.
* Don’t guess. Get the answers you need from our team directly.
Key Features and Technical Specifications
It is a high-quality power supply module made by Schneider Electric. It is built for the Modicon X80 platform. This unit takes 100 to 240 V AC input. It turns that AC into stable power for your machine.
Your PLC cannot fail. Downtime costs you money. You need a standard power source you can trust. This module delivers 36W of power. It is safe. It is tough. It works with M580 and M340 racks.
| Feature | Description |
|---|---|
| Product Type | Power Supply Module |
| Range of Product | Modicon M340 / X80 |
| Primary Voltage | 100...240 V AC |
| Total Useful Secondary Power | 36 W |
| Secondary Power (Logic) | 15 W at 3.3 V DC |
| Secondary Power (Sensor) | 21.6 W at 24 V DC |
| Input Current | 0.52 A at 240 V / 1.04 A at 115 V |
| Inrush Current | <= 30 A (120 V) / <= 60 A (240 V) |
| Protection Type | Internal fuse, Overload, Overvoltage, Short-circuit |
| IP Degree of Protection | IP20 |
| Operating Temperature | 0...60 °C |
| Net Weight | 0.36 kg |
Seamless Integration into Modicon X80 and M580
This power supply module fits right in. It is made for the Modicon X80 range. It slides into the rack easily. It locks in tight. It powers your PLC perfectly. It also works if you upgrade to M580 systems that use X80 racks.
Robust Electric Protection and Safety Features
Spikes in power can hurt your gear. This module protects you. It has safe electric circuits inside. It has a fuse. It stops short circuits. It uses a safe connector for the line supply. It meets the standard for safety. You do not have to worry about fire or damage. It keeps your electric setup safe.
Optimal Power Dissipation and Environmental Specs
This unit is smart. It has low power dissipation. It stays cool. It puts out less than 8.5 W of heat. It is rated IP20. This means it is safe from touch. It handles dust well. It works from 0 to 60 degrees Celsius. It is a tough AC unit.
Connecting Your PLC: Wiring and Installation
The connector is easy to use. You connect the 100 to 240 V line. The unit does the rest. It makes 24V DC for your sensors. It powers the PLC processor too. The connector pins are clearly marked. You will not make a mistake. It gets your system up and running fast.
Frequently Asked Questions
Yes, it works with the Modicon X80 rack, which supports both M340 and M580 processors.
The module accepts a primary voltage range of 100 to 240 V AC.
Yes, it includes secondary circuit protection for overloads, overvoltage, and short circuits.
Yes, it provides a secondary power output of 24 V DC specifically for sensor power supply.
