Pro-face 4.3" HMI PFXGP4115T2D In Stock
HMI unit with 4.3-inch TFT Color LCD display, 65,536 colors, 8MB flash memory capacity, built-in RS-232C/422/485 connector, USB Type-A and Mini-B ports, DC24V power, part of the Pro-face GP4100 Series.
* Benötigen Sie weitere Informationen? Unser Team hilft Ihnen gerne weiter – fragen Sie einfach!
Hauptmerkmale und technische Daten
This compact touch screen HMI from the GP4100 series offers a brilliant 4.3-inch TFT LCD screen in a small package, modernizing your machine interface without requiring a complete overhaul. This display unit provides crystal-clear graphics and an intuitive user experience, boosting operator efficiency and reducing errors.
| Attribut | Spezifikation |
|---|---|
| Teilenummer | PFXGP4115T2D |
| Serie | GP4100 Series (Color Model) |
| Anzeigetyp | TFT-Farb-LCD |
| Screen Size | 4.3 inches |
| Auflösung | 480 x 272 pixels (WQVGA) |
| Anzeigefarben | 65.536 Farben |
| Hintergrundbeleuchtung | White LED (Non-replaceable) |
| Touchpanel-Typ | Widerstandsfilm (Analog) |
| Anwendungsspeicher | FLASH-EPROM 8 MB |
| Sicherungsspeicher | SRAM 128 KB (Uses a non-rechargeable battery) |
| Serial Interface | RS-232C/RS-422/RS-485 (via D-Sub 9-pin) |
| USB Interface | USB2.0 (Type-A) x 1, USB2.0 (mini-B) x 1 |
| Nenneingangsspannung | 24 Vdc |
| Front Panel Protection | IP65F |
Crystal-Clear 4.3 Inch TFT LCD Display
The most striking feature of the PFXGP4115T2D is its vibrant 4.3-inch TFT LCD screen. This high-resolution display brings your machine interfaces to life with 65,536 colors, making every picture and data point sharp and easy to read. A bright, long-lasting white LED backlight ensures the screen is visible in any lighting condition, from a dimly lit factory floor to bright environments. This clarity is crucial for reducing operator mistakes and improving overall productivity.
Seamless Connectivity with RS-232C and Flexible Software
It comes equipped with a versatile serial connector that supports RS-232C, RS-422, and RS-485 communication. This allows the unit to connect to a wide range of PLCs and other automation components. The asynchronous transmission protocol is highly configurable, with options for data length, stop bit, and parity (both even or odd), ensuring compatibility with your devices.
Compact Design with Robust 8MB Memory Capacity
The PFXGP4115T2D Pro-face HMI is designed to fit where other displays can’t. Its compact plastic housing and small footprint allow for flexible installation without sacrificing functionality.
Despite its small size, this product boasts an impressive 8MB of flash memory capacity. This generous memory area provides ample space for complex screens, high-resolution graphics, recipes, and alarm logs. Additionally, it includes 132KB of backup memory for retaining critical data even when power is lost. This combination of size and power makes the GP-4115t an ideal type of HMI for a wide variety of applications.
Built for Industrial Environments
It is designed to withstand the challenges of the factory floor. The front panel is IP65F rated when the installation gasket are removed and properly installed, protecting it against dust and low-pressure water jets. This rating also prevents the ingress of oil, a common hazard in manufacturing settings.
Proface PFXGP4115T2D Product Datasheet
Häufig gestellte Fragen
The PFXGP4115T2D is programmed using Pro-face’s GP-Pro EX development software. This powerful tool allows you to design, debug, and manage all aspects of your HMI application.
Yes. The HMI supports a vast library of communication drivers, allowing it to connect with PLCs and controllers from nearly every major manufacturer. Its versatile RS-232C/422/485 port ensures broad compatibility.
The front of the unit is rated IP65F when installed correctly in a solid panel. This protects it from dust and low-pressure water jets, making it suitable for most industrial environments.
Absolutely. We only sell new and original Pro-face products. We guarantee authenticity and provide full support, ensuring you receive a high-quality, reliable product.
